Wire Drawings

DM Class 500

26 Ga. Galvalume (FL# 27499.20)
.032" Aluminum (FL# 27499.21)

• Available in 21" or 24" wide coverage. Some restrictions apply
• Over 15/32" Plywood
• 20 Year Warranty on Fasteners Available
• Class A Fire Rated
• Miami-Dade & Broward Counties Approved
• High Velocity Hurricane Zone (HVHZ) Approved
• Resting Leg Allows for Thermal Expansion

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 800

0.032" Aluminum (FL# 30751.6)
26 Ga. Galvalume (FL# 30751.7)

• Available in 15 1/2" wide coverage
• Over 15/32" Plywood
• High Velocity Hurricane Zone (HVHZ) Approved
• Class A Fire Rated
• Miami-Dade & Broward Counties Approved
• 10' Continuous Clip Available
• Salt Water Finish Warranties Available

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 1000

26 Ga. Galvalume (FL# 27499.1)
.032" Aluminum (FL# 27499.2)

• Available in 16'' wide coverage
• Over 15/32" Plywood
• High Velocity Hurricane Zone (HVHZ) Approved
• Class A Fire Rated
• Miami-Dade & Broward Counties Approved
• Salt Water Finish Warranties Available

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 1050

.032" Aluminum (FL# 27499.3)
24 Ga. Galvalume (FL# 27499.4)

• Available on 19'' or 15'' wide coverage
• Over 15/32" Plywood
• High Velocity Hurricane Zone (HVHZ) Approved
• Class A Fire Rated
• Miami-Dade & Broward Counties Approved
• Salt Water Finish Warranties Available

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 1150

.032 Aluminum HVHZ (FL# 27499.5)
.032 Aluminum Non-HVHZ  (FL# 27499.6)
26 Ga. Galvalume (FL# 27499.7)

• Available in 13”, 17” or 21” wide coverage
• Over 15/32” Plywood
• Class A Fire Rated
• High Velocity Hurricane Zone (HVHZ) Approved
• Miami-Dade & Broward County Approved
• Saltwater Warranty Available
• Mechanically Locked Seams

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 1500

.032" Aluminum 20" wide (FL# 27499.8)
16 oz. Copper 16" wide (FL# 27499.9)
26 Ga. Galvalume 16" wide (FL# 27499.10)
.032" Aluminum 16" wide (FL# 27499.11)
24 Ga. Galvalume 16" wide (FL# 27499.12)
24 Ga. Galvalume 20" wide (FL# 27499.13)

• Available in Steel, Aluminum & Copper
• Available in 16'' or 20'' wide coverage
• Over 15/32" Plywood
• Class A Fire Approved
• High Velocity Hurricane Zone (HVHZ) Approved
• Miami-Dade & Broward Counties Approved
• Salt Water Finish Warranties Available

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 1700

.032" Aluminum (FL# 30751.3)
26 Ga. Galvalume (FL# 30751.4)
26 Ga. Galvalume Non-HVHZ (FL# 30751.5)

• Available in 15'' or 19'' wide coverage
• Over 15/32" Plywood
• Class A Fire Rated
• High Velocity Hurricane Zone (HVHZ) Approved
• Miami-Dade & Broward Counties Approved
• Salt Water Finish Warranty Available
• Allows for Thermal Expansion

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 1750

24 Ga. Galvalume, attached to metal deck. (FL# 27499.14)
.032" Aluminum, attached to metal deck. (FL# 27499.15)
.032" Aluminum (FL# 27499.16)
24 Ga. Galvalume (FL# 27499.17)

• Available in 14'' and 18'' wide coverage
• Over B-Deck Steel Deck
• Over 15/32" Plywood
• High Velocity Hurricane Zone (HVHZ) Approved
• Class A Fire Rated
• Miami-Dade & Broward Counties approved
• Salt Water Finish Warranty Available
• Available for Commercial Buildings

Extras

• Flashing DetailsDownload

Wire Drawings

DM Class 2000

.032 Aluminum (FL# 27499.18)
24 Ga. Galvalume (FL# 27499.19)
24 Ga. Galvalume 18“ wide (FL# 32041.1)

• Available in 14'' and 18'' wide coverage
• Over 15/32" Plywood
• High Velocity Hurricane Zone (HVHZ) Approved
• Miami-Dade & Broward Counties Approved
• Salt Water Finish Warranty Available

Extras

• Flashing DetailsDownload
